Key Spec:
LCD Size: 5'' IPS
Resolution: 720X1280 , portrait
Brightness: 400nits
interface: mipi
Touch : Yes, In-cell technology
Working Temperature:-20C~+70℃
Storage Temperatture:-30C~+80℃
In-cell TFT LCD Technology
Touch function is optional
Ultra thin dimension
Popular size for hand-held instrument
Multi-scenario application
| Manufacture | Hello Lighting | Place of Origin | China |
| P/N | HL050T48C-01 | Resolution | 720X1280 |
| Interface | mipi | Luminance | 400nits |
| LCD mode | IPS | Touch | Incell/Optional |
| OD size(mm) | 64.8X118.6(LCD only) | AA Size | 61.6X110 |
| View angle | 85/85/85/85 | Surface treatment | AR(Anti-Reflection) |
| Op. Temp. | -20~+70℃ | St. Temp. | -30~+80℃ |
Customized for hand-held beauty equipment
For Industrial Thermal Imager
For Handheld Acoustic Imager Industrial Ultrasonic Imager
For Industrial Endoscope monitor
For outdoor GPS
IATF16949 certification
ISO9001 certification
High-tech Enterprise Certification
Fully automated production line
