Products
| IMG | Inquire | Size | P/N | Resolution | Interface | Luminance | Viewing Angle | OD Size(mm) | Op.Temp | St.Temp | Datasheet |
|---|---|---|---|---|---|---|---|---|---|---|---|
 |
Inquire | 1.78 | HL017T03-01 | 368x448 | MIPI | 350nits | IPS | 30.6X37.99x0.8 | -20~+70℃ | -30~+80℃ | Download |
 |
Inquire | 2.14 | HL020E21-01 | 480x480 | MIPI,SPI,QSPI | 600nits | IPS | 40.29X41.09x0.8 | -20~+70℃ | -30~+80℃ | Download |
 |
Inquire | 2.4 | HL024T01-01 | 240x320 | RGB,MCU | 200nits | 6 o'clock | 42.72X60.26x2.25 | -20~+70℃ | -30~+80℃ | Download |
 |
Inquire | 3.5 | HL035T33-01 | 1920x1080 | MIPI | 500nits | IPS | 87.1X56.8X2.7 | -20~+70℃ | -30~+80℃ | Download |
 |
Inquire | 3.5 | HL035T15-01 | 320x480 | RGB | 350nits | IPS | 54.66X82.94X3.68 | -20~+70℃ | -30~+80℃ | Download |
|
Inquire | 3.5 | HL035T15-01 | 320x480 | RGB | 350nits | IPS | 54.66X82.94X3.68 | -20~+70℃ | -30~+80℃ | Download |
 |
Inquire | 3.7 | HL037T04-02 | 480x110 | RGB | 500nits | IPS | 105.24X34x3.9 | -20~+70℃ | -30~+80℃ | Download |
 |
Inquire | 4.3 | HL043T011-01 | 480x272 | RGB | 300nits | 12 o'clok | 105.5x67.2X2.95 | -20~+70℃ | -30~+80℃ | Download |
 |
Inquire | 4.3 | HL043T35-06 | 800x480 | RGB | 350nits | IPS | 105.5x67.2X3.0 | -30~+85℃ | -40~+90℃ | Download |
|
Inquire | 4.3 | HL043T31C-04 | 480x272 | RGB | 300nits | IPS | 123.04x84.46x4.8 | -20~+70℃ | -40~+80℃ | Download |
 |
Inquire | 5 | HL050T48C-01 | 720x1280 | MIPI | 400nits | IPS | 64.8X118.6 | -20~+70℃ | -30~+80℃ | Download |
 |
Inquire | 5 | HL050O02-01 | 720x1280 | MIPI | 400nits | IPS | 65.92X118.64 | -20~+70℃ | -30~+80℃ | Download |
 |
Inquire | 5 | HL050E02C-01 | 720x1280 | MIPI | 400nits | IPS | 71.92X127.14 | -20~+70℃ | -30~+80℃ | Download |
 |
Inquire | 5 | HL050T27C-02 | 1080x1920 | MIPI | 2000nits | IPS | 75.88X119.47X2.8 | -20~+70℃ | -30~+80℃ | Download |
 |
Inquire | 6.86 | HL064T01-01 | 1024x768 | LVDS | 400nits | IPS | 140.65X110.5X4.83 | -30~+85℃ | -35~+85℃ | Download |
 |
Inquire | 5 | HL050T40-01 | 640x480 | RGB | 1000nits | 6 o'clock | 113.7X88.5X4.8 | -20~+70℃ | -30~+80℃ | Download |
 |
Inquire | 5.2 | HL052T04-01 | 1200x1200 | MIPI | 1000nits | IPS | 110X105X4.2 | -20~+70℃ | -30~+80℃ | Download |
 |
Inquire | 5.5 | HL055O11-03 | 1080x1920 | MIPI | 500nits | IPS | 69.74×126.6x0.66 | -20~+70℃ | -30~+80℃ | Download |
 |
Inquire | 5.7 | HL057T13R-01 | 640x480 | RGB | 500nits | IPS | 127X98.43X5.85 | -20~+70℃ | -30~+80℃ | Download |
 |
Inquire | 6.86 | HL068T02-01 | 280x1424 | MIPI | 300nits | IPS | 38.2×181.47x3.4 | -30~+80℃ | -35~+85℃ | Download |
 |
Inquire | 6.86 | HL068T01-01 | 480x1280 | RGB | 300nits | IPS | 66.90X181.20x4.6 | -20~+70℃ | -30~+80℃ | Download |
.jpg) |
Inquire | 7 | HL070T20-01 | 1024x600 | LVDS | 400nits | IPS | 164.9X100X3.55 | -20~+70℃ | -30~+80℃ | Download |
 |
Inquire | 7 | HL070T51-01 | 1024x600 | HDMI | 400nits | IPS | 165.3X121 | -20~+70℃ | -30~+80℃ | Download |
|
Inquire | 7 | HL070T51-01 | 1024x600 | HDMI | 400nits | IPS | 165.3X121x7.75 | -20~+70℃ | -30~+80℃ | Download |
 |
Inquire | 7 | HL070T60-01 | 800x480 | LVDS | 1000nits | IPS | 165X104X6.9 | -30~+85℃ | -40~+90℃ | Download |
 |
Inquire | 7 | HL070T55-01 | 1200x1920 | MIPI | 1500nits | IPS | 105.46X162.82X2.4 | -20~+70℃ | -30~+80℃ | Download |
 |
Inquire | 7 | HL070T15-01 | 800x480 | RGB | 500nits | 6 o'clock | 164.9X100.0X3.55 | -20~+70℃ | -30~+80℃ | Download |
 |
Inquire | 7 | HL070T24-01 | 800x480 | RGB | 400nits | 6 o'clock | 165X104.44X5.2 | -20~+70℃ | -30~+80℃ | Download |
 |
Inquire | 8 | HL080T21-02 | 800x1280 | MIPI | 1000nits | IPS | 114.8X184.2X2.65 | -10~+60℃ | -20~+70℃ | Download |
 |
Inquire | 10.1 | HL101T33-01 | 1920x1080 | LVDS | 1000nits | IPS | 237.69X142.7x7.2 | -40~+85℃ | -40~+90℃ | Download |
 |
Inquire | 10.1 | HL101T36-01 | 1280x800 | LVDS | 1000nits | IPS | 229.46X149.1X2.5 | -20~+70℃ | -30~+80℃ | Download |
 |
Inquire | 10.1 | HL101T22-08 | 1200x1920 | MIPI | 1000nits | IPS | 148.42×228.54×2.6 | -10~+60℃ | -20~+70℃ | Download |
 |
Inquire | 10.25 | HL103T03-01 | 1920x720 | LVDS | 1000nits | IPS | 258.9X111.1 | -40~+85℃ | -40~+90℃ | Download |
|
Inquire | 10.25 | HL103T01-01 | 1280x480 | LVDS | 800nits | IPS | 258.6X109.8X7.6 | -40~+85℃ | -40~+90℃ | Download |
 |
Inquire | 10.4 | HL104T08-01 | 1024x768 | LVDS | 1000nits | IPS | 233.40X175.80X6.6 | -30~+80℃ | -40~+85℃ | Download |
 |
Inquire | 12.3 | HL123T02C-01 | 1920x720 | LVDS | 800nits | IPS | 305.23X128.51X7.9 | -40~+85℃ | -40~+90℃ | Download |
 |
Inquire | 15.6 | HL156T18C-01 | 1920x1080 | HDMI | 500nits | IPS | 395X244X21 | 0~+50℃ | -10~+60℃ | Download |
 |
Inquire | 17.3 | HL173T04-01 | 3840x2160 | EDP | 1500nits | IPS | 412.85X266.39X14.4 | 0~+50℃ | -20~+60℃ | Download |
 |
Inquire | 23.8 | HL238T06-06 | 3840x2160 | EDP | 1300nits | IPS | 570X340X11.7 | 0~+50℃ | -20~+60℃ | Download |
