Key Spec:
LCD Size: 5'' OLED
Resolution: 720X1280
Brightness: 400nits
interface: MIPI
Working Temperature:-20~+70℃
Storage Temperatture:-30C~+80℃
AMoled with lower power consumption
Outdoor application
full replacement of H497TLB01_4
Very thin
| P/N | HL050E02C-01 | Resolution | 720X1280 |
| Interface | MIPI | Luminance | 400nits |
| Viewing Angle | 89/89/89/89 | Touch | Oncell touch |
| OD Size(mm) | 71.92x127.14x2.25mm | AA Size(mm) | 61.88x110.02mm |
| Op.Temp | -20C~+60℃ | St.Temp | -30C~+70℃ |
